Usage:
Technical features
1. Can complete the processes of pre-stamping, metering, box turning, separating from the box, and so on automatically
2. The main body adopts a frame structure, vertical double boxes, good rigidity, and high stability.
3. Touch screen and fault analysis system, simple operation, and convenient maintenance.
4. Adopting plug-in valve, PLC controller, reliable performance.
5. The auxiliary system completes the processes of picking bags, delivering bags, weighing bags, and delivering automatically
Technical parameters:
|
型号 |
出包方式 |
产量 |
公称力 |
功率（kw） |
包重(kg) |
包型 |
打包方式 |
|
Model |
Bale Out |
Throughput （approx.） |
Nominal Pressure |
Motor |
Bale Weight |
Bale Size（L×W×H） |
Type of tying |
|
MDY400 |
液压提升门 Hydraulic lifting door |
20包Bales |
4000KN |
82.4 |
227±10 |
1400×530×700 |
钢丝/塑带 Steel wire / Plastic tape |
|
MDY400A |
25包Bales |
97.4 |
|||||
|
MDY400B1 |
30包Bales |
120.85 |
|||||
|
MDY400B2 |
45包Bales |
158.85 |
